Get Expert Help With Your Touch Design

The following companies have proven touch and Human-Machine Interface (HMI) design expertise as verified by Microchip. Please contact any of these companies for design services and support for your touch project needs.

Partner_logos-compset1

Find a Touch Design Partner by Specialty:

MCU-Based Touch Solutions—Buttons, Sliders, Wheels, Touchpads

Design Partner Location(s) Contact Information Key Benefits

AMTouch USA		 Wisconsin, USA
Europe		 sales@amtouchusa.com
+1-414-847-1814

CapExt AS		 Oslo,
Norway
 		 info@capext.com
+47 977 08 997
  • Fast and easy to use capacitive simulation tool
  • Time and cost saver in any project
  • Standard tool at Microchip for simulating touch

Demmel AG		 Germany, Europe marcus.riegger@demmel.de
+49 8381 919 0

INES - Innovation Electronic Software		 France, Europe contact@ines-rd.com
+33 (0) 2 41 48 49 44

Martin Technologies		 France, Europe +33 2 41 21 41 21

Quad Industries		 Belgium, Europe Web Form
+32 (0) 3-722 03 03

RAFI		 Berg, Germany eric.bulach@rafi.de
+49 751 89-1495

Schaeftner Engineering		 Germany, Europe daniel.schaeftner@schaeftner-engineering.com
+49 (0) 171 15 86 382

2D Touch: maXTouch® Technology Touchscreen Partners

Design Partner Location(s) Contact Information Key Benefits

BOE Varitronix Limited		 Hong Kong, China info@boevx.com
+852 2197 6000
  • Leading automotive touch module supplier
  • Vertical integration of LCM and touch panels
  • Rich experience in LCD manufacturing
  • Leading passive LCD and TFT shipments
  • Strong technical team and support
  • Quality and service system (IATF16949, ISO9001, etc.)

DATA MODUL		 New York, USA
Munich, Germany		 USA
KFrederick@data-modul.com
+1-858-735-2026
Germany
NSenMutlu@data-modul.com
+49 89 56017 155
  • Display distributor
  • Standard sensor lineup 3.5” to 23.8”
  • Custom sensor designs
  • Local presence in EU countries and USA (East/West coast offices)
  • In-house optical bonding and lamination
  • On-site FAE support

DAWAR Technologies, Inc.		 Pennsylvania, USA Tony Gray
tgray@dawar.com
+1-972-491-1260
  • Support for glass and film sensors
  • US-based low-volume production
  • Asia-based manufacturing for high-volume projects
  • In-house OCR bonding

EDT (Emerging Display Technologies)		 Kaohsiung, Taiwan Max Wu
service@edt.com.tw
+886-7-812-4832 (ext 2023)
  • One-stop shop for touchscreen displays and smart embedded systems
  • TN and IPS TFT, monochrome and low-power display technology
  • In-house cover lens, bezel and housing integration assembly
  • Display and touch panel optical bonding (OCA and OCR), air bonding
  • Custom cover lens materials, coatings and processes
  • Custom touch panels and touch tuning configurations available
  • One Glass Solution (OGS), GG, GGG, TOL and film sensor designs
  • ISO 9001, ISO 14001, IATF16949, QC080000, OHSAS 18001 and ISO 13485 certification
  • Global network with local presence and support in the U.S., Europe and Asia

ELO Touch		 Taipei, Taiwan
Texas, USA
Leuven, Belgium		 Taiwan
steven.lai@elotouch.com
+886 2 7743 3660
USA
Brian.Atwood@elotouch.com
+1-919-649-8445
Belgium
michael.bartelmess@elotouch.com
+32 16 704 509
  • Offers IntelliTouch® Pro PCAP touchscreens from 7" to 55"
  • Manufacturing facilities in California and China
  • Supports glass and film sensors
  • Strong global sales and support

Fannal Electronics		 Hangzhou, China Lesen Ding
Sales@fannal.com
+86 (571) 8516-1516
  • One-stop shop for touchscreen/displays/optical bonding
  • In-house full manufacturing process
  • Flexibility on MOQ
  • Competitive prices and services

Goworld (Shantou Goworld Display Co., Ltd)		 Shantou, China Samic Su
samicsu@goworld-lcd.com
+86 0754-89892463
  • Leading automotive touch supplier
  • Vertical integration of LCM and touch panel
  • Production capacity
  • Broad touch patent portfolio
  • Quality and service system

Grayhill Inc		 Illinois, USA matt_huner@grayhill.com
+1-708-482-2100
  • Specialize in full touch solution including mechanical, hardware and software design
  • Offer touch products integrated both on and off the display, putting the power of touch right next to the operator
  • Ability to integrate touch, pressure sensing and haptic response in one module or product
  • Offer standard products when needed to minimize design time and development costs
  • Software integration libraries and protocol that minimizes customer integration time

Haizhiwang		 Shenzhen, China James Man (Business)
+86-755-82577465
James@haiwangtech.com
Kerr Wei (Technical)
tech@haiwangtech.com
  • Hardware design and tuning support services from design to mass production
  • Standard TP/TPLCM module offering
  • Customization services
  • Turnkey Human Machine Interface (HMI) design and solution
  • Flexible business models

MSC Technologies GmbH		 Stuntensee, Germany Stefano.rosato@avnet.eu
+49 8165 906 300
  • Broad standard module offering
  • Customizations of sensors
  • Display distributor
  • Local presence in EU countries
  • One glass/nanowire solution support

NVD (New Vision Display)		 Asia
Europe
USA		 Asia
GregorySmith@newvisiondisplay.com
+86 755 2862 0888
Europe
MohamedHaider@newvisiondisplay.com
+1-508-344-4269
USA
ShahnaKothapally@newvisiondisplay.com
+1-972-522-9509
  • Vertically integrated one-stop LCM provider
  • Owns and operates three factories in China
  • Manufactures passive and active LCDs
  • In-house chemically strengthened cover glass manufacturing
  • Glass and film-based PCAP sensors up to 25" with glove, water, salt water, and stylus support

PDA (Precision Design Associates)		 Georgia, USA
Taipei, Taiwan		 USA
Phil Wills
+1-770-664-0448
Taiwan
Vincent Yeh
+886-933-207-523
  • Engaged with Quantum Research Group before Atmel and Microchip acquisitions
  • Broad standard module offering
  • Flexible outsourced sensor supply chain
  • Flexible business models
  • Flexible sensor stack/pattern

Promate		 Taipei, Taiwan
Shanghai, China
California, USA
Breda, The Netherlands		 Taiwan + USA
ricky_chen@promate.com
+886 2 2659 0606
China
ricky_chen@promate.com
+86-18411031125
The Netherlands
wilco_bos@promate.com
+31 0 85 0021465
  • Turnkey mission critical human machine interface (HMI) design and manufacturing
  • High performance display and touch panel optical bonding
  • Display enhancements: ruggedize, sunlight readability
  • Sensor/circuit design, PCB layout and SMT capabilities
  • Software integration support, multi-OS

RAFI		 Berg, Germany eric.bulach@rafi-group.com
+49 751 89-1495
  • Strong industrial, medical and commercial vehicle market expertise
  • Specialist in all kinds of HMI devices
  • Hardware, software, mechanical design and production
  • Sensor design and production
  • Glass (up to 24") and film sensor
  • Own glass sensor production
  • Clean room facilities

Tianma Japan, Ltd.		 Kawasaki, Japan Web Form
+81 44 435 1666
  • Broad product offering with true industrial design and one-stop shop including displays with touch panels
  • World-class factories with cutting-edge R & D
  • Strategic commitment to manufacturing with a focus on supporting professional display products and long product life policy

Touch International		 Texas, USA sales@touchintl.com
+1-512-832-8292
  • Vertically integrated OEM solutions provider
  • Touch panels/optical filters - 0.5" to 90"
  • In-house display enhancement - sunlight readable/NVIS/dual-mode
  • Dry film and liquid optical bonding
  • Low volume/high mix - high volume repeatable
  • ISO9001, AS9100, ISO13485, RoHS2, REACH, ITAR

TouchTurns		 California, USA shiou.huang@touchturns.com
+1-408-645-2607
  • Touch display
  • Laser ablation and drilling
  • Forging, stamping
  • MIM and 3D printing:
    • Sintering and HIP
    • Binder jet and SLM
  • PVD coating
  • Surface treatment
  • Speciality covers:
    • Glass and ceramic glass
    • Camera lens
      • 2.5D and 3D

Uni-Electronics/Gallardo		 Tokyo, Japan suyama@uni-elec.co.jp
+81-3-6811-7478
  • Wide variety of capacitive touchscreens and buttons
  • Hardware design and manufacturing support
  • Tuning support is also available with specialized equipment
  • Configuration tuning (software support) available
  • Very fast time to market
  • Flexible sensor stack/pattern

Yantai Zhenghai Technology Co., Ltd.		 Shandong, China jiangml@zhenghai.com
+86-535-6930108
  • One-stop solution from cover lens to touch sensor to TDM (OCA direct bonding with LCM)
  • High-quality vertically integrated in-house manufacturing
  • Global support experience with multi-regional OEM customers
  • Flexible sensor construction with silver, copper, and ITO materials on either glass or film substrates

Design Resources

Design Partners

Learn more about how our design partners can accelerate your time to market.

Learn More About Our Design Partner Ecosystem
Aerospace and Defense Design Partners

Contact Us

We are here to support you. Contact our Client Success Team to get assistance with your design.











Browse Inventory

Browse the largest selection of Microchip parts.

Browse Inventory

Learn About Standard, Off-the-Shelf Touch Modules:

2D Touch: maXTouch Technology Touchscreen Display Modules

Size
(")		 Resolution Vendor Name Display OEM Module Part Number maXTouch® Controller
Part Number		 Sensor Channels Touch
Interface*		 Display Interface Brightness
(nits)		 Viewing Angle Operating Temp (°C) Purchase Vendor Comments**
7.0 800 × 480 Data Modul Innolux eTD070W2201-INA-A mXT640T 30X 18Y USB-HID,
USB-Vendor		 LVDS 500 70/70/60/60 −20 to +70 Info DM
7.0 800 × 480 Promate Solutions AUO DM-070W3TF0 mXT1664T3   I2C, USB-HID,
I2C-HID		 TTL 560 80/80/80/80 0 to +60 Info PM1
7.0 800 × 480 EDT CTC ETML070023MDRA mXT640UD 30X 18Y I2C-OBJ 24-bit RGB 850 80/80/80/80 −30 to +85 Info
5.0 720 × 1280 TouchTurns TDO TT00050LSTD mXT336U 14X 24Y I2C-OBJ MIPI® 350 80/80/80/80 −20 to +70 Info TT
5.0 800 × 480 EDT BOE ETML050023MDRA mXT336UD 23X 14Y I2C-OBJ 24-bit RGB 850 80/80/80/80 −30 to +85 Info
4.5 480 × 854 Goworld Display Co Goworld Display Co GWMD14947 mXT224T   I2C-OBJ MIPI DSI 450 80/80/80/80 −20 to +70 Info
4.3 480 × 272 EDT Hannstar ETML043023MDRA mXT336UD 21X 12Y I2C-OBJ 24-bit RGB 850 80/80/80/80 −30 to +85 Info
3.5 320 × 240 EDT Hannstar ETML035023MDRA mXT336UD 14X 11Y I2C-OBJ 24-bit RGB 850 80/80/80/80 −30 to +85 Info
3.5 480 × 320 TouchTurns EAST-R TT00035LSTD mXT336U 10X 15Y I2C-OBJ SPI 280 70/70/70/50 −20 to +70 Info TT
4.3 480 × 272 TouchTurns TDO TT00043LSTD mXT336U 14X 24Y I2C-OBJ 24-bit RGB 500 80/80/80/80 −30 to +70 Info TT
3.5 320 × 480 Goworld Display Co Goworld Display Co DM13116 mXT336T   I2C-Vendor 16-/18-bit RGB 300 60/55/60/60 −20 to +70 Info
10.3 1920 × 720 Promate Solutions BOE 97J103Z7A0 mXT2952T2   I2C, USB-HID,
I2C-HID		 LVDS 850 85/85/85/85 −30 to +85 Info PM1
10.1 1280 × 800 EDT INX ETML101013MDHA
ETML101013MDRA
ETML101013LMDHA
ETML101013LMDRA		 mXT1664T3 41X 26Y USB-HID 8-bit LVDS 380
850
380
850		 85/85/85/85 −20 to +70 Info
12.3 1920 x 720 Promate Solutions AUO 97C123H2A0 mXT2952T2   I2C, USB-HID,
I2C-HID		 LVDS 600 80/80/80/80 −30 to +85 Info PM1
21.5 1920 × 1080 Promate Solutions AUO 97G215H1A0 mXT2952TD/ mXT2952T2   I2C, USB-HID,
I2C-HID		 LVDS 350 89/89/89/89 0 to +60 Info PM1
13.3 1920 × 1080 Data Modul AUO eTD133W3202-AUA-A

mXT2952T2

 41X 71Y USB-HID,
USB-Vendor		 LVDS 400 89/89/89/89 0 to +70 Info DM
15.6 1920 × 1080 Data Modul Sharp eTD156W3202-SHA-A mXT2952T2 41X 71Y USB-HID,
USB-Vendor		 LVDS 400 85/85/85/85 -20 to +75 Info DM
18.5 1920 × 1080 Data Modul AUO eTD185W3302-AUA-A mXT2952T2 41X 71Y USB-HID,
USB-Vendor		 LVDS 350 89/89/89/89 -20 to +70 Info DM
21.5 1920 × 1080 Data Modul AUO eTD215W3302-AUA-A mXT2952T2 41X 71Y USB-HID,
USB-Vendor		 LVDS 250 89/89/89/89 0 to +60 Info DM
15.6 1366 × 768 Dawar Technologies Tianma DW03178-B mxT1664T3   USB-OBJ
(USB 2.0 with
Microchip standard
object protocol)		 VGA, HDMI 400   −10 to +60 Buy PM1
15.6 1366 × 768 Data Modul Innolux eTD156W3202-INA-A mXT2952T2 41X 71Y USB-HID,
USB-Vendor		 LVDS 300 80/80/80/80 0 to +60 Info DM
15.6 1366 × 768 Promate Solutions AUO DM-156E1TF0 mXT2952TD/ mXT2952T2   I2C, USB-HID,
I2C-HID		 LVDS 320 85/85/80/80 0 to +60 Info PM2
10.1 1280 × 800 New Vision Display OSD OSD0101T4317-71TS mXT1066T2 41X 26Y I2C-OBJ,
I2C-HID		 LVDS 820 80/80/80/80 −20 to +70 Buy
10.1 1280 × 800 Data Modul Innolux eTD101W3201-INA-A mXT640T 20X 32Y USB-HID,
USB-Vendor		 LVDS 500 85/85/85/85 −20 to +65 Info DM
10.1 1280 × 800 TouchTurns STARTEK TT00101LSTD mXT1664T3 28X 44Y USB-HID LVDS 350 85/85/85/85 0 to +50 Info TT
10.1 1280 × 800 Promate Solutions AUO DM-101E1TF0 mXT2952T2   I2C, USB-HID,
I2C-HID		 LVDS 320 85/85/85/85 −10 to +60 Info PM1
10.1 1280 × 800 Dawar Technologies K & D DW03166-B mxT1664T3   USB-OBJ
(USB 2.0 with
Microchip standard
object protocol)		 VGA, HDMI 650 85/85/85/85 −10 to +60 Buy
12.1 1280 × 800 TouchTurns KYOCERA TT00121LSTD mXT1664T3 32X 52Y USB-HID LVDS 500 85/85/85/85 −20 to +70 Info TT
12.1 1280 × 800 Data Modul Innolux eTD121W3202-INA-A mXT2952T2 41X 67Y USB-HID,
USB-Vendor		 LVDS 400 88/88/88/88 −20 to +80 Info DM
7.0 1280 × 800 TouchTurns TIANMA TT00070LSTD mXT336T 24X 14Y I2C-OBJ LVDS 400 80/80/80/80 −20 to +70 Info TT
12.1 1024 × 768 Dawar Technologies Tianma DW03177-B mxT1664T3   USB-OBJ
(USB 2.0 with
Microchip standard
object protocol)		 VGA, HDMI 400   −10 to +60 Buy
12.1 1024 × 768 Promate Solutions AUO DM-121X1TF0 mXT2952TD/ mXT2952T2   I2C, USB-HID,
I2C-HID		 LVDS 400 80/80/70/70 −30 to +70 Info PM1
15.0 1024 × 768 Promate Solutions AUO DM-150X3TF0 mXT2952TD
mXT2952T2		   I2C, USB-HID,
I2C-HID		 LVDS 280 80/80/70/80 0 to +65 Info PM1
3.5 320 × 480 Fannal Fannal FN0350T018A ATMXT336U-MAUR021 8X 12Y I2C RGB 300 60/55/60/60 −20 to +70 Info
7 800×480 Fannal Fannal FN0700T115A ATMXT640U-CCUR023 27X 15Y I2C RGB 950 60/55/60/61 −20 to +70 Info
8 1024×68 Fannal Fannal FN0800T009A ATMXT1664T3-CCUR035 25X 19Y USB LVDS 250 85/85/85/85  -10 to +60 Info
10.1 1280x800 Fannal Fannal FN1010T064A ATMXT1066TD-C2UR001 32X 20Y I2C LVDS 1000 85/85/85/85 −20 to +70 Info
10.1 1024x600 Fannal Fannal FN1010T065A ATMXT640U-CCUR023 32X 18Y I2C LVDS 600 85/85/85/85 −20 to +70 Info
12.1 1024*768 Fannal Innolux FN1210T036A ATMXT1664T3-CCUR035 25X 33Y I2C, USB LVDS 600 85/85/85/85 −20 to +70 Info
13.3 1920*1080 Fannal AUO FN1330T018A ATMXT1664T3-CCUR035 49X 28Y USB LVDS 400 85/85/85/85 −20 to +70 Info
15 1024*768 Fannal AUO FN150AM008-V2.0 ATMXT1664T3-CCUR035 42X 32Y USB LVDS 350 80/80/70/80  -0 to +65 Info
15.6 1920*1080 Fannal AUO FN1560T026A ATMXT1664T3-CCUR035 52X 32Y USB LVDS 500 89/89/89/89 −20 to +70 Info
18.5 1920*1080 Fannal AUO FN1850T007A ATMXT2952TD-C2UR001 52X 32Y USB LVDS 350 89/89/89/89  -30 to +80 Info
21.5 1920*1080 Fannal BOE FN2150T019A ATMXT2952TD-C2UR001 61X 34Y USB LVDS 250 89/89/89/89  -0 to +50 Info
23.8 1920*1080 Fannal AUO FN2380T004A ATMXT2952TD-C2UR001 71X 40Y USB LVDS 400 89/89/89/89  -0 to +50 Info
27 1920*1080 Fannal BOE FN2700T002A ATMXT2952TD-C2UR001 71X 41Y USB LVDS 300 89/89/89/89  -0 to +50 Info
32 1920*1080 Fannal BOE FN3200T008A ATMXT2952TD-C2UR001 71X 41Y USB LVDS 400 89/89/89/89  -0 to +50 Info

* Touch Interface
I2C-OBJ (I2C with Microchip standard object protocol)
I2C-HID (I2C with HID protocol)
I2C-Vendor (I2C with proprietary vendor specified protocol)
USB-OBJ (USB 2.0 with Microchip standard object protocol)
USB-HID (USB 2.0 with with "HID" protocol)
USB-Vendor (USB 2.0 with proprietary vendor specified protocol)
SPI (Serial Peripheral Interface)

**Vendor Comments
DM This off-the-shelf product is open to customization. Please contact DATA MODUL with your requirements. MOQ rules for customization should be considered. Additionally,video interface module available with options of DVI, VGA, DP, or HDMI input to be ordered separately.
TT Cover glass can be customized per customer requirements without  changing the sensor design.
PM1 1.8mm Cover Glass with chemical strengthening, This off-the shelf product is open to customization. MOQ rules for customization should be considered.
PM2 2.8mm Cover Glass with chemical strengthening, This off-the shelf product is open to customization. MOQ rules for customization should be considered.

2D Touch: maXTouch Technology Touch Sensors (Without Displays)

Size (") Cover Glass Thickness (mm) Vendor Name Module Part Number maXTouch®  Controller Part Number Touch Controller Mounting Sensor Channels Sensor Electrode Pitch (mm) Touch Interface* Touch Sensor Stackup** Purchase Vendor Comments***
4.3 1.1 Data Modul eTP043W2102-CS mXT640T COF (Chip on Flex) 20X 12Y 4.8 OBJ-I2C  GFF Info DM1
4.3 1.1 New Vision Display TP2147SA043C-01 mXT336U COF (Chip on Flex)   4.0 I2C-OBJ GG Info NVD
4.3 1.1 Dawar Technologies DW03044-B mXT336U COF (Chip on Flex)   6.75 I2C-OBJ
(I2C with Microchip
standard object protocol)		 GG
(DITO - Two- Layer/
Double Sided)		 Buy
5.0 1.1 Data Modul eTP050W2102-CS mxT640T COF (Chip on Flex) 28X 17Y 4.0 OBJ-I2C  GFF Info DM1
5.0 1.1 New Vision Display TP2131SA050C-02 mXT336U COF (Chip on Flex)   4.7 I2C-OBJ GG Info NVD
7.0 2.0 Data Modul eTP070W2203-PS mXT640U
mxT640T		 None (Passive Tail,
MXT COB
sold separately)		 30X 18Y 5.2 HID-USB,
OBJ-I2C 		 GFF Info DM2
7.0 0.7 Data Modul eTP070W2103-PS mXT640U
mxT640T		 None (Passive Tail,
MXT COB
sold separately)		 30X 18Y 5.2 HID-USB,
OBJ-I2C 		 GFF Info DM2
7.0 1.8 Promate Solutions 81F070YF2A0F-PS mXT1664T3 COF (Chip on Flex)     USB, I2C GFF Info PM1
7.0 1.1 New Vision Display TP2132SA070L-01 mXT224T COF (Chip on Flex)   8.3 I2C-OBJ GG Info NVD
7.0 1.1 New Vision Display TP2135SA070C-01  mXT449T-AT COF (Chip on Flex)   6.6 I2C-OBJ GG Info NVD
7.0 1.1 Dawar Technologies DW02264-B None None (Passive Tail,
MXT COB available
separately)		   7.5 None
(MXT board
available
separately)		 GG
(DITO - Two-Layer/
Double Sided)		 Buy
8.0 1.1 Data Modul eTP080W2103-PS mXT640U
mxT640T		 None (Passive Tail,
MXT COB
sold separately)		 32X 20Y 5.4 HID-USB,
OBJ-I2C 		 GFF Info DM2
8.0 1.1 Dawar Technologies DW02739-A None None (Passive Tail,
MXT COB available
separately)		 32X 20Y 7 None
(MXT board
available
separately)		 GG
(DITO - Two-Layer/
Double Sided)		 Buy
10.1 2.0 Data Modul eTP101W1203-PS mXT640U
mxT640T		 None (Passive Tail,
MXT COB
sold separately)		 20X 32Y 7.0 HID-USB,
OBJ-I2C 		 G1G1 Info DM2
10.1 1.8 Promate Solutions 81F101YFBA0F-PS mXT2952T2 COF (Chip on Flex)     USB, I2C GFF Info PM1
10.1 1.1 Dawar Technologies DW03081-A None None (Passive Tail,
MXT COB available
separately)		   7.2 None
(MXT board
available
separately)		 GG
(DITO - Two-Layer/
Double Sided)		 Buy
10.3 1.8 Promate Solutions 81F103HT0A0F-PS mXT2952T2 COF (Chip on Flex)     USB, I2C GFF Info PM1
10.4 0.7 Data Modul eTP104S2103-PS mXT640U
mxT640T		 None (Passive Tail,
MXT COB
sold separately)		 27X 20Y 8.0 HID-USB,
OBJ-I2C 		 GFF Info DM2
12.1 2.0 Data Modul eTP121W1204-PS mXT2952T2 None (Passive Tail,
MXT COB
sold separately)		 41X 67Y 4.0 HID-USB G1G1 Info DM2
12.1 1.8 Promate Solutions 81B121YF3A0F-PS mXT2952TD
mXT2952T2		 COB (Chip on Board)     USB, I2C GFF Info PM1
12.1 1.1 Dawar Technologies DW03047-A None None (Passive Tail,
MXT COB available
separately)		   7.4 None
(MXT board
available
separately)		 GG
(DITO - Two-Layer/
Double Sided)		 Buy
12.3 1.8 Promate Solutions 81F123HT0A0F-PS mXT2952T2 COF (Chip on Flex)     USB, I2C GFF Info PM1
13.3 2.0 Data Modul eTP133W1204-PS mXT2952T2 None (Passive Tail,
MXT COB
sold separately)		 41X 71Y 4.1 HID-USB G1G1 Info DM2
15.0 1.8 Promate Solutions 81B150YF2A0F-PS mXT2952TD/
mXT2952T2		 COB (Chip on Board)     USB, I2C GFF Info PM1
15.6 2.0 Data Modul eTP156W1204-PS mXT2952T2 None (Passive Tail,
MXT COB
sold separately)		 41X 71Y 4.8 HID-USB G1G1 Info DM2
15.6 2.8 Promate Solutions 81B156YF2A0F-PS mXT2952TD/
mXT2952T2		 COB (Chip on Board)     USB, I2C GFF Info PM2
15.6 1.8 Dawar Technologies DW03050-A None None (Passive Tail,
MXT COB available
separately)		   6.9 None
(MXT board
available
separately)		 GG
(DITO - Two-Layer/
Double Sided)		 Buy
18.5 3.0 Data Modul eTP185W1304-PS mXT2952T2 None (Passive Tail,
MXT COB
sold separately)		 41X 71Y 5.7 HID-USB G1G1 Info DM2
19.0 1.1 Data Modul eTP190S2104-PS mXT2952T2 None (Passive Tail,
MXT COB
sold separately)		 41X 51Y 7.5 HID-USB GFF Info DM2
21.5 3.0 Data Modul eTP215W1304-PS mXT2952T2 None (Passive Tail,
MXT COB
sold separately)		 41X 71Y 6.6 HID-USB G1G1 Info DM2
21.5 1.8 Promate Solutions 81B121YF3A0F-PS mXT2952TD mXT2952T2 COB (Chip on Board)     USB, I2C GFF Info PM1

* Touch Interface
I2C-OBJ (I2C with Microchip standard object protocol)
I2C-HID (I2C with "HID" protocol)
I2C-Vendor (I2C with proprietary vendor specified protocol)
USB-OBJ (USB 2.0 with Microchip standard object protocol)
USB-HID (USB 2.0 with with "HID" protocol)
USB-Vendor (USB 2.0 with proprietary vendor specified protocol)
SPI (Serial peripheral Interface)

** Touch Sensor Stackup
OGS/TOL/G2 (One Glass Solution - 2 Layer with bridges)
OGS/TOL/G1 (One Glass Solution - 1 Layer, no bridges)
G1G1 (1 layer ITO on cover glass + 1 layer ITO on sensor glass, SITO)
GG (Glass/Glass, 2 Layer/Double Sided ITO on sensor glass, DITO)
GFF (Glass/Film/Film)
GF/GF1 (Glass/Film - 1 Layer sensor without bridges, SITO)
GF2 (Glass/Film - 2 Layer/Double Sided)

***Vendor Comments:
DM1 available only as chip-on-flex
DM2 Please contact DATA MODUL for corresponding controller board
PM1 1.8mm Cover Glass with chemical strengthening, This off-the shelf product is open to customization. MOQ rules for customization should be considered.
PM2 2.8mm Cover Glass with chemical strengthening, This off-the shelf product is open to customization. MOQ rules for customization should be considered.
NVD Request pricing information through NVD contact form.

Search All Design Partners
Get Help Finding a Design Partner

Touchscreen Design Partner Introduction

This video describes some of the challenges associated with touchscreen controller design, and introduces our maXTouch® touch sensor module partners as a tool to reduce complexity and lower risk.
