Privacy PolicyExtended-Range, Ultra-Low-Power Sub-1-GHz Modules and ICs for Robust Sensor Networks
Sub-GHz devices operate at lower frequencies, allowing signals to broadcast over long distances and to penetrate obstacles such as walls and buildings. Sub-1-GHz frequencies also have less interference than the 2.4-GHz band, which is crowded with signals from Wi-Fi® and Bluetooth® devices.
For these reasons, sub-GHz is the go-to wireless technology for applications requiring robust performance and low power consumption.
We offer a wide range of industry-leading sub-GHz modules and SoCs to suit a variety of applications. Along with offering a large selection of devices, we provide industry-leading support. When combined with our advanced development boards, free software stacks and demo code, it’s easier than ever to use our sub-GHz products.
Sub-GHz Devices Portfolio
Our industry-leading sub-GHz modules and SoCs, which operate in the license-free ISM frequency bands from 315 MHz to 928 MHz, are designed for low-power applications. Going beyond power consumption, we offer a large selection of highly integrated sub-GHz devices that will suit your requirements. For greater functionality, our sub-GHz products also support IEEE® 802.15.4 and proprietary wireless standards. Explore our selection of sub-GHz modules and SoCs to find the device that is right for your project.
Transceivers
- Designed for bidirectional remote control and access systems
- Fast challenge-response crypto functionality
- Same size and current consumption as unidirectional
Transmitters
- AVR® microcontroller core with robust, field-proven RF transmitter
- Well-suited to smart metering, alarm systems and home automation applications
Receivers
- Designed for low-cost, low-power-consumption RF data transmission systems
- Adaptable to a wide range of applications including automotive and industrial
LoRa®
- Ultra-low-power, easy-to-use devices for long-range end nodes
- Well-suited to smart city, smart agriculture and supply chain/tracking applications
Browse All Sub-GHz Products
Take a deep dive into device specifications and compare products side by side using our product selection tools.
Featured Products
SAM R30 Sub-GHz MCU Module and SiP
All-in-One Solution
- Ultra-low-power microcontroller and 802.15.4 radio
- Reliable sub-GHz connectivity for sensors requiring communication through exterior walls
- Extremely low-power sleep modes for multiple years of battery life
- Proprietary self-healing mesh connectivity
AT86RF215 Dual-Band Transceiver
Flexible, 2.4-GHz and Sub-GHz Solution
- Simultaneous 2.4-GHz and sub-GHz operation
- Highly flexible device supporting a variety of data rates with three modulation schemes
- IEEE 802.15.4-2011, IEEE 802.15.4g-2012 and ETSI TS 102 887-1 compliant
- Well-suited to smart meter and smart city applications
Why Choose Our Sub-GHz Solutions?
Integrated Design
Our sub-GHz portfolio delivers the industry’s largest link budget. We achieve these results by offloading system-level functions from the MCU to reduce power and computation burden.
Broad Data Rate and Transmission Support
Our sub-GHz product portfolio supports OOK, ASK, FSK, O-QPSK and ORDM modulations with data rates from 1 kbps to 2,400 kbps.
Broad Frequency and Range Support
We support all ISM frequency bands and offer the only commercially available device that supports 2.4-GHz and sub-GHz bands simultaneously.
High Sensitivity
Low-IF receivers provide high sensitivity, high blocking and low intermodulation, eliminating the need for bulky blocking Surface Wave Acoustic (SAW) filters in remote control units.
Low Current Consumption
We provide low current consumption in all three modes—operation, idle and sleep—to give you long battery life (in some cases years).
Adjustable Power Output
Our sub-GHz transceivers provide an adjustable power range starting at -17 dBm and going up to +14.5 dBm.
Key Markets and Applications
Consuming about 75% less power than Wi-Fi, sub-GHz is the optimal wireless technology for low-cost, robust and low-power sensor networks such as metering, smart building and smart city applications.
Smart Energy
- Smart meters
- Solar farms
- Electric Vehicle (EV) chargers
Building Automation
- Alarm systems
- Remote controls
- Access control systems
Smart City
- Intelligent lighting
- Traffic and parking management
- Waste management
Featured Application
RF Remotes
We provide stand-alone transceivers and receiver products and a family of rfPIC transmitters with an embedded PIC® microcontroller that can be used to create RF remotes. These radio solutions are well-suited for Automatic Meter Reading (AMR), consumer electronics, home, business, industrial automation, automotive, toys and medical applications.
Getting Started
We Have All Tools Needed to Jumpstart Your Project
Our comprehensive selection of tools and accessible support makes sub-GHz product development easy. Our resources include:
- Modules, SoCs and other devices
- Development boards
- Detailed documentation
- Demo applications
- Wireless design check service
- Technical support
- Development Tools
- Development Environments
SAMR30M Xplained Pro Evaluation Kit
- Features the SAMR30M18A module
- Includes extension headers for adding peripherals
SAMR30M Sensor Board
- Features the SAMR30M18A module
- Includes mikroBUS™-compatible headers for adding click board-based sensors
SAMR30 Xplained Pro Evaluation Kit
- Features the SAMR30M18A SoC
- Includes extension headers to extend your design
AT86RF215 Xplained Pro Extension Board
- Features the AT86RF215 transceiver
- Evaluates performance in the sub-GHz and 2.4 GHz bands
MPLAB® Harmony v3
This integrated software development framework for our SAM and PIC32 MCUs provides flexible and interoperable modules that simplify product development and reduce time to market.
Microchip Studio
Seamlessly develop and debug AVR and SAM microcontroller applications with this easy-to-use Integrated Development Environment (IDE).
Software Stacks
Along with supporting IEEE 802.15.4 wireless standards, our sub-GHz products also support proprietary wireless protocols including IP500 and Wi-SUN. Learn more about these technologies below.
- IP500
- Wi-SUN Alliance
IP500
IP500 meets the highest requirements for robust and secure wireless networks in smart cities, factories, buildings and homes. These products are well-suited for mission-critical applications such as intrusion, evacuation or fire detection systems. They can be found in:
- Battery-free, energy-harvesting light switches
- Alarm sensors that require years of battery life
- High-performance mesh utility networks supporting smart meters and street lighting
We are one of the device leaders that support this robust mesh network protocol by providing a complete solution:
- AT86RF215: RF front end
- ATSAM4LC8BA: controller
Wi-SUN Alliance®
We are proud to be a member of the Wi-SUN (Wireless Smart Utility Networks) Alliance, which was formed to drive the adoption of smart utility networks. The Wi-SUN Alliance:
- Defines communications profiles that are based on the IEEE 802.15.4g, 802.15.4e, IPv6, 6LoWPAN and UDP standards
- Offers testing and certification to further ensure interoperability
Like the IEEE standard for Wi-Fi, the Wi-SUN Alliance delivers harmonized operation of products from multiple suppliers.
With multi-modulation, both the AT86RF215M and AT86RF215 802.15.4 sub-GHz transceivers are advanced Wi-SUN solutions. Our partner Exegin provides the complete Wi-SUN stack and tools.
Is Sub-GHz Right for Your Project?
- Benefits
- Countries and Bands
Sub-GHz Device Benefits
Sub-GHz, sometimes called sub-1-GHz, refers to the radio frequencies that fall below 1 GHz on the electromagnetic spectrum. These frequencies are significant in the wireless industry due to their unique characteristics and advantages.
Longer Range
Firstly, sub-GHz signals possess excellent broadcast capabilities, allowing them to travel over long distances and penetrate obstacles such as walls and buildings more effectively than higher frequencies. This characteristic makes sub-GHz technology well-suited for applications that require wide coverage, such as smart cities, industrial automation, agriculture and utilities.
Robust and Reliable
Sub-GHz frequencies also offer improved robustness and reliability in challenging environments. They are less susceptible to interference from other wireless devices that operate at higher frequencies, providing more stable communication. This makes sub-GHz technology optimal for applications that demand high reliability and security, such as wireless sensor networks, remote monitoring and control systems.
Efficient Power Consumption
Lastly, sub-GHz solutions often have lower power consumption compared to higher-frequency alternatives, resulting in extended battery life for wireless devices. This energy efficiency is particularly valuable in applications where frequent battery replacement or recharging is impractical or costly.
In summary, sub-GHz frequencies play a crucial role in the wireless industry by enabling reliable, long-range communication with excellent penetration capabilities and low power consumption.
The 315 MHz and 433 MHz bands are used globally, but the other bands are only supported in specific regions. Here are some of the most popular sub-GHz bands and frequencies used around the world:
- 868 MHz: primarily used in Europe
- 915 MHz: primarily used in North and South America
- 920 MHz: primarily used in Asia
- 779 MHz: primarily used in China
