Highly Efficient and Linear RF Power Amplifiers
We have a proven track record in providing Power Amplifier solutions across many frequencies and power levels. Our power amplifiers support demanding system requirements for mobile applications, commercial infrastructure, and a variety of military and space systems, but also compliment a wide range of other broad solutions. Our power amplifier technologies and products support up to 31 GHz and improve Size, Weight, and Power (SWaP), and drive next-generation performance in your designs. Our power amplifiers are highly efficient and provide a strong linearity characteristic across these many broad solutions and application designs.
Aerospace and Defense
Extensive range of S-band to mm-wave MMICs and GaN and GaAs Power Amplifiers.
- 3–70W, 1–31 GHz, S-band through Ka band
- S-band 70W, 60% PAE in plastic QFN
- CW and pulsed output power
- Very flat P-out over the band of interest
Satellite Communication
High-efficiency, high-gain Ka, Ku band amplifiers up to 35W.
- Stable performance in back-off conditions
- Extensive thermal characterizations to deliver stable operation
Wireless Infrastructure
Power Amplifiers for mm-wave 5G network applications.
- High-linearity, best-in-class SWAP
- 50 ohm matched with integrated blocking capacitors
