Motor Control, Dual CAN, USB Connectivity, Speech and Audio, High-Pin Count Options
Motors can be found in a wide range of applications and end markets. In most of these designs, it is essential that they run efficiently and consume as little power as possible. dsPIC33EP MU family of Digital Signal Controllers (DSCs) offers 70 MIPS performance, a Digital Signal Processing (DSP) engine and specialized motor control peripherals that enable you to implement high-efficiency, high-precision, variable-speed, constant-torque Proportional Integrated (PI) control and Field Oriented Control (FOC) in your design for higher energy efficiency and quieter operation.
The dsPIC33EP MU family is ideal for controlling a variety of motors, including stepper motors, Brushless DC (BLDC) motors, Permanent Magnet Synchronous Motors (PMSMs), AC Induction Motors (ACIMs) and Switched Reluctance Motors (SRMs). The dsPIC33EP MU DSCs feature two master time base modules to control dual 3-phase motors simultaneously, a high-speed Analog-to-Digital Converter (ADC), op amps and comparators to optimize your design. The high-level of analog integration reduces your Bill of Materials (BoM) cost and design form factor. Offering up to 150°C operation, the dsPIC33EP MU family of DSCs can facilitate a robust motor control design capable of withstanding harsh environments found in industrial and automotive applications.
The dsPIC33EP MU family also features large pin-count options with packages up to 144 pins, large Flash memories of up to 512 KB and 52 KB of SRAM, making these DSCs excellent solutions for high-end embedded applications, such as multi-sensor control systems and speech/audio products. The large RAM enables these DSCs to run complex filtering software that requires large data buffers, making them well suited for speech recognition, noise and echo cancellation applications. Free DSP filter software, noise suppression and echo cancellation libraries are provided to speed your design development. In addition, the dsPIC33EP MU family also features a Full Speed USB host and device and a high-speed Direct Memory Access (DMA) controller to enable easy connectivity to external systems and PCs.
Automotive
- Under-the-hood
- Camera control
- Home link systems
Automotive
- Fans and fuel pumps
- Compressors
- Heating circulation pumps
- Fleet tracking
- Cabin noise cancellation
Industrial
- 3D printers
- CNC machines
- Sewing machines
- CAN controllers
- Equipment automation controllers
Consumer
- Power tools
- Lawn mowers
- Security systems
- Noise and echo cancellation
- Speech compression
- MP3/MP4 playback
Communications
- Telecom hubs
- Optical fiber hubs
- Multi-touch interfaces
dsPIC33EP MU Family Selection Guide
motorBench® Development Suite
Motor Control Design Center
Innovative Peripherals
Similar Devices
- Development Tools
- Software Development Tools
- Documentation
- Software
Development Tools
Starter Kits and Microsticks
Development boards for motor control and digital power applications range from simple starter kits to complete development platforms.
Digital Power Starter Kit: Allows the user to easily explore the capabilities and features of the dsPIC33F GS Digital Power Conversion family
Low-Voltage Motor Control Development Bundle: For evaluation of motor control application with 5V or dual motors
MCHV-2 Development Board: Provides a cost-effective method of evaluating and developing high-voltage sensored or sensorless Brushless DC (BLDC), Permanent Magnet Synchronous Motor (PMSM) and AC Induction Motor (ACIM) applications
MCLV-2 Development Board: Provides a cost-effective method of evaluating and developing low-voltage sensored or sensorless Brushless DC (BLDC) and Permanent Magnet Sychronous Motor (PMSM) applications
Motor Control Starter Kit: Demonstrations support mTouch Capacitive Touch technology and BLDC motor control
Development and Evaluation Boards
The Explorer 16/32 platform is the primary development board for 16-bit products. Explorer 16/32 is supplemented by numerous application-specific development boards including PICtail™ Plus boards and Click boards™ from MikroElektronika.
Explorer 16/32 Development Board: A modular and flexible development board for dsPIC® DSCs, with integrated programmer/debugger
Processor Plug-In Modules: Processor-specific Plug-in Modules
PICtail Plus Expansion Boards: Expansion board allowing evaluation of complex hardware and software solutions
Motor Control and Digital Power
Development boards for motor control and digital power applications range from simple starter kits to complete development platforms.
Digital Power Starter Kit: Allows the user to easily explore the capabilities and features of the dsPIC33F GS Digital Power Conversion family
Low-Voltage Motor Control Development Bundle: For evaluation of motor control application with 5V or dual motors
MCHV-2 Development Board: Provides a cost-effective method of evaluating and developing high-voltage sensored or sensorless Brushless DC (BLDC), Permanent Magnet Synchronous Motor (PMSM) and AC Induction Motor (ACIM) applications
MCLV-2 Development Board: Provides a cost-effective method of evaluating and developing low-voltage sensored or sensorless Brushless DC (BLDC) and Permanent Magnet Sychronous Motor (PMSM) applications
Motor Control Starter Kit: Demonstrations support mTouch Capacitive Touch technology and BLDC motor control
Emulators and Debuggers
The debuggers and programmers are USB powered and are fully integrated with MPLAB® X IDE with features ranging from basic debugging to advanced emulation capability.
MPLAB REAL ICE™ In-Circuit Emulator: Next generation high-speed programmer and debugger with optional LVDS interconnect
MPLAB ICD 3: Cost-effective high-speed programmer and debugger
PICkit™ 3 In-Circuit Debugger/Programmer: Low-cost programmer and debugger
Software Development Tools
MPLAB® X IDE
This single Integrated Development Environment (IDE) supports all PIC MCUs and dsPIC DSCs. It provides a single integrated "environment" to develop code for embedded microcontrollers. It includes a library of Microchip-validated code examples to get started right away and integrates the MPLAB XC16 compiler while featuring "One Click" Make, Program, Debug/Execute operation.
MPLAB® Code Configurator
This free graphical programming environment generates seamless, easy-to-understand C code. Using an intuitive interface, it enables and configures a rich set of peripherals and functions. It minimizes reliance upon the product data sheet and reduces overall design effort and time while accelerating generation of production-ready code.
MPLAB® XC Compilers
MPLAB XC16 compilers provide a comprehensive solution for a project’s development software needs and comes in different optimization levels. It integrates with MPLAB X IDE to provide a full graphical front end. It can edit errors and create breakpoints to match the corresponding lines in source code. Single step through C and C++ source code to inspect variables and structures at critical points.
MPLAB® Xpress Cloud-Based IDE
This online development environment contains the most popular features of our award-winning MPLAB X IDE. It is a perfect starting point for new users of PIC MCUs with no downloads, no machine configuration, and no waiting to get started. Join the MPLAB Xpress Community to share code, ideas and knowledge.
Application Notes
|
Title
|
|
|---|---|
| Sensorless Field Oriented Control (FOC) for a Permanent Magnet Synchronous Motor (PMSM) Using a PLL Estimator and Field Weakening (FW) | Download |
| Using the PIC MCU CTMU for Temperature Measurement | Download |
| Sensored BLDC Motor Control Using dsPIC Digital Signal Controllers (DSCs) | Download |
| Microchip TCP/IP Stack Application Note | Download |
| Low-Power Design Guide | Download |
| AN1375 - See What You Can Do with the CTMU | Download |
| Stepper Motor Control with dsPIC® DSCs | Download |
| Single-Shunt Three-Phase Current Reconstruction Algorithm for Sensorless FOC of a PMSM | Download |
| Offline UPS Reference Design Using the dsPIC DSC | Download |
| Digital Power IPFC Reference Design Application Note | Download |
| AN1229 - Class B Safety Software Library for PIC MCUs and dsPIC DSCs | Download |
| AN1227 - Using a Keyboard with the Microchip Graphics Library | Download |
| Switch Mode Power Supply (SMPS) Topologies (Part II) | Download |
| AN1182 - Fonts in the Microchip Graphics Library | Download |
| AN1145 - Using a USB Flash Drive with an Embedded Host | Download |
| USB Human Interface Device Class on an Embedded Host | Download |
| AN1142 - USB Mass Storage Class on an Embedded Host | Download |
| AN1140 - USB Embedded Host Stack | Download |
| AN1136 - How to Use Widgets in Microchip Graphics Library | Download |
| Switch Mode Power Supply (SMPS) Topologies (Part I) | Download |
| Power Factor Correction in Power Conversion Applications Using the dsPIC® DSC | Download |
| AN1071 - IrDA Standard Stack for Microchip 16-Bit and 32-bit MCUs | Download |
| File I/O Functions Using Microchip's Memory Disk Drive File System Library | Download |
| Data Encryption Routines for PIC24 and dsPIC Devices | Download |
| Developing Graphics Apps using PIC MCUs w/Integrated Graphics Controller | Download |
| Implementing a Mass Storage Device Using the Microchip USB Device Firmware Framework | Download |
Brochures
|
Title
|
|
|---|---|
| eXtreme Low Power (XLP) PIC® MCUs Brochure | Download |
Code Examples
|
Title
|
|
|---|---|
| CE003 Driving a BLDC With Sinusoidal Voltages Using dsPIC30F | Download |
The MPLAB® development environment is a single tool chain supporting dsPIC® Digital Signal Controllers.
- Bootloader for dsPIC33 – Microchip Easy Bootloader for dsPIC33, or EZBL, is a library of software and example projects
- Code Examples – Includes a comprehensive list of code snippets to peripherals and modes to speed your code development.
- Microchip Libraries for Applications (MLA) – Source code and demo code for USB, Graphics, File I/O and more
- MPLAB® Code Configurator – is a free graphical programming environment that generates seamless, easy to understand C code
- MPLAB® X IDE – Single Integrated Development Environment supports all PIC MCUs and dsPIC DSCs
- MPLAB® XC Compilers – Full featured MPLAB XC Compilers with free downloads available
- MPLAB Xpress Cloud-based IDE – MPLAB Xpress Cloud-Based IDE is an online development environment that contains the most popular features of our award-winning MPLAB X IDE
- nanoWatt XLP Battery Life Estimator – See how long the battery will last in your target application entering basic use case for low power MCUs
- Real Time Data Monitoring Tool (RTDM ) – Tool developed to Data Monitor and Control Interface (DMCI), which addresses the need for monitoring and modifying data in a real-time fashion
- Software Tools – Supplemental software tools for 16-bit PIC® MCUs and dsPIC® DSCs
- Third Party RTOS – RTOS supporting Microchip PIC MCUs and dsPIC DSCs
- XC16 Compiler User's Guide
PIC24 MCUs and dsPIC33 DSCs | Easy Migration in a Platform Design
This video will introduce you to the common development ecosystem that allows for easy migration across device families and enables you to use the low-power PIC24F MCUs and the robust dsPIC33 DSCs in a complete platform design.
dsPIC® DSCs Perform Under Pressure
dsPIC® DSCs Perform Under Pressure
This video will demonstrate how the dsPIC DSCs can help you get your design done on schedule and avoid the deadline pressure.
