PIC16F74 | Microchip Technology

Overview

  • Program Memory Size (KB):7
  • RAM:192
  • Data EEPROM (bytes):0
  • Pin Count:40
  • Operation Voltage Max.(V):5.5
  • Operation Voltage Min.(V):2
  • ADC Resolution Max:8
  • ADC Channels:8
  • Zero Cross Detect:False
  • Number of Comparators:0
  • SPI:1
  • I2C:1
  • Stand alone PWM:0
  • Low Power:No
  • Numerically Controlled Oscillator (NCO):0
  • Data Signal Modulator (DSM):0
Read more
  • 2 PWM 10-bit
    25mA sink/source per I/O
    2 Capture/Compare
    Parallel Slave Port
