Overview
Alternate products
Compare Products
(2)
- Program Memory Size (KB):7
- RAM:192
- Data EEPROM (bytes):0
- Pin Count:40
- Operation Voltage Max.(V):6
- Operation Voltage Min.(V):2.5
- ADC Resolution Max:0
- ADC Channels:0
- Zero Cross Detect:False
- Number of Comparators:0
- SPI:1
- I2C:1
- Stand alone PWM:0
- Low Power:No
- Numerically Controlled Oscillator (NCO):0
- Data Signal Modulator (DSM):0
- ROM: 4096x14 Parallel Slave Port 2 Capture/Compare 2 PWM 10-bit
Use your up or down key to switch images.
Tools And Software
Development Environment
| Tools |
|---|
 MPLAB® X Integrated Development Environment (IDE) is an expandable, highly configurable software program that incorporates powerful tools to help you discover, configure, develop, debug and qualify embedded designs for most of Microchip’s microcontrollers, microprocessors and digital signal controllers.
|
| Available as free, unrestricted-use downloads, our award-winning MPLAB® XC C Compilers are comprehensive solutions for your project’s software development.
|
