Overview
- Product Type:Projected Capacitive Controller
- Input Channels:27
- Output Channels:0
- Measurement Principle:Self/Mutual Capacitance
- Report Rate (pps):100
- Number of Touches:10
- Power Modes:0
- Position Resolution:16-bit
- I/O, LED Drivers:0
- Other Features:Gestures, USB or I2C comm., 27RX and 19TX channels supported
- Voltage Min. (V):2.60
- Voltage Max. (V):3.60
- Multi-Touch up to 10 touches
- 5 touches typically at 100Hz+ each
- 27RX x 19TX channels support approximately 8” touch screens (larger possible)
- Combines with MTCH652 for superior signal-to-noise ratio (SNR)
- Integrated single and multi-finger gesture recognition suite including taps, swipes, scrolling, and pinching and zooming
- Advanced DSP processing provides noise avoidance techniques
- USB & I2C communication
- Supports 3D gestures up to 20cm when combined with the MGC3130 GestIC® controller
- 27RX 19TX Sensor
- 27 mA full-scan rate
- 1 mA reduced-scan rate
- Touch screen designs that need cost effective, easy to integrate, fast time to market PCap touch solutions
- Perfect for touch screens over displays, control panels, keypads, and many other input devices
- Targeting the Industrial, Medical, Home & Office Automation, and Consumer markets among others
Microchip offers a wide portfolio of capacitive touch controllers. The maXTouch portfolio covers solutions for all touch surfaces and touch screens up to 24” diagonal size.
