MCP6V61U | Microchip Technology

Overview

  • CMRR Min (dB):120
  • Enhanced EMI Protection:Yes
  • Gain Bandwidth Product kHz (kilohertz):1000
  • Iq Max (uA):130
  • Input Voltage Noise Density (nV/rt(Hz)):26
  • Iq Typical (µA):80
  • Operating Voltage Max V (volt):5.5
  • Operating Voltage Min V (volt):1.8
  • PM (deg):60
  • PSRR Min (dB):117
  • # Per Package:1
  • Slew Rate (V/µs):0.45
  • Vos Max µV (microvolt):8
Read more
  • Zero Drift architecture
  • Maximum offset of only 8 uV
  • Maximum offset drift of 15 nV/C
  • No 1/f noise
  • GBWP of 1 MHz
  • Enhanced EMI Rejection
  • Small SC-70 and SOT-23 packaging
