Ultra Low Density FPGAs
Overview
Alternate products
Compare Products
(2)
- Analog:No
- Data Security:No
- FPGA I/O Max:No
- Total RAM Kbit (kilobit):144
- Fabric ROM Kbit (kilobit):1
- Fabric uPROM Kbit (kilobit):No
- LogicElements(K):11
- Max. MSS I/O (3.3V) Max:No
- Math Blocks 18x18:No
- PCIe Lanes:No
- Product Type:ProASIC3
- Temp Max °C (degrees Celsius):125
- Temp Min °C (degrees Celsius):-55
- eNVM(KB) KB (kilobyte):No
- eSRAM(KB) KB (kilobyte):No
- 11K logic elements
- 144Kb RAM
- 1Kb FlashROM
- 1 PLL in CCC
- Temperature - Commercial, Industrial, Military
ProASIC3
offers high performance in ultra low dendity FPGAs, a single-chip solution,
small footprint packages, reprogrammability, and an abundance of advanced
features. M1 ProASIC3 devices support the high-performance, 32-bit Cortex-M1
soft processor developed by ARM for implementation in FPGAs.
Key Features
• Low TOC (total cost of ownership)
• System performance of 350 MHz
• Proven Security
• Protection from Overbuilding and Cloning
• Exceptional Reliability
Key Features
• Low TOC (total cost of ownership)
• System performance of 350 MHz
• Proven Security
• Protection from Overbuilding and Cloning
• Exceptional Reliability
Use your up or down key to switch images.
Tools And Software
Development Environment
Emulator and Debuggers
Programmers
| Tools |
|---|
 Our comprehensive, easy-to-learn and easy-to-adopt development tools allow you to design with our power-efficient FPGAs.
|
| Start designing your embedded system today with our comprehensive design suite for our FPGAs, SoC FPGAs and radiation-tolerant FPGAs.
|
| Tools |
|---|
| FlashPro5 offers high performance through USB 2.0 that supports Serial Peripheral Interconnect (SPI) and JTAG interfaces.
|
| Silicon Sculptor 4 CE-compliant production device programmer works alongside Silicon Sculptor adapter modules to program the FPGA devices. It concurrently programs large FPGA parts without performance degradation.
|
