FRED-600V

Name: FRED-600V
Brand: Microchip Technology
SKU: 16704
Availability: InStock

Status: In Production

600V Ultrafast Soft Recovery Rectifier Diode

Data Sheet:

Download Datasheets

Overview Documentation Tools And Software Design Resources Similar Devices Purchase Related Videos

Overview

product_type:Silicon Discrete Diode
Reverse Voltage [max] Max:600
Forward Current (A) [max]:20 - 100
Forward Voltage [typ]:1.25 - 3.2
Reverse Recovery Time (ns) [typ]:17 - 160
Package Type:D3PAK, SOT-227, T-MAX, TO-220, TO-247, TO-264

Ultrafast recovery times
Soft recovery
Low leakage current
Avalanche energy rated
AEC-Q101 qualified (FRED DQ in TO-247, TO-220 and TO-264)
Higher switching frequency
Low switching losses
Low noise (EMI) switching
Easy to parallel
Improved system reliability
AC-DC/DC-DC converters
Inverters
Switch mode power supply
H/EV chargers
H/EV onboard chargers & powertrain

Microchip offers four series of discrete diode products: the medium-speed medium Vf D series, the high-speed DQ series, the silicon Schottky S series and the SiC Schottky MSCxxxSDxxxx series. These series of diodes are designed to provide high-quality solutions to a wide range of high-voltage, high-power application requirements, ranging from fast recovery for continuous conduction mode power factor correction to low conduction loss for output rectification.

FRED-600V is a family of 600V Ultrafast Soft Recovery Rectifier Diode available in a variety of current and package options
