8-bit PIC Microcontroller
Overview
- ADC Resolution b (bits):12
- Number of Comparators:2
- Data EEPROM (bytes):256
- Data Signal Modulator (DSM):0
- MVIO Pins:0
- Numerically Controlled Oscillator (NCO):1
- Operation Voltage Max.(V):5.5
- Operation Voltage Min.(V):1.8
- RAM Bytes:2048
- Program Memory size (KB):28
- Low Power:Yes
- ADC Channels:35
- Pincount:28
- Stand alone PWM:2
- Zero Cross Detect:0
The PIC16F181xx family’s advanced analog peripherals are specifically well-suited for raw sensor applications requiring signal gain or filtering. It is the first product family to offer a 12-bit differential ADC with computation in low pin count packages. The combination of advanced analog and several digital communication peripherals makes this family ideal for enhanced sensing applications.
