Overview
- Power Options:STANDARD
- Operating Voltage Min (V):4.5
- Operating Voltage Max (V):5.5
- Inputs and I/O Pins:36
- Registers:32
- Macrocells:32
- tPD Min:10
- Max Clock Freq:125
- Temp# Range Min (deg C):-40
- Temp# Range Max (deg C):85
Mature product, not recommended for new designs. Replaced by ATF1502ASV
