Part Number: PD70100EVB15B
PD WITH PD70100
- Featuring PD70100
- IEEE 802.3af/at/ standard compliant
- 15W power Buck topology
- Designed to support one PDchip application (2-pairs)
- Two RJ45 connectors (data and power in, data out)
- Optional Wall adapter – DC in connector
- Output voltage connectors
- On board LED indicator
- Pulse transformers and common mode chocks
- Evaluation board working temperature: 0°C to +70°C
Overview
The PD70100EVB15B evaluation board provides designers with the needed environment to evaluate the performance and implementation of PD applications based on PD70100 PD chip. The evaluation board enables PD designers to evaluate Microchip's PDchip solution.
Package Contents
N/A
