Part Number: ATSAMC20-QTRDEMO
SAM C20 QTOUCH ROBUSTNESS EVALUATION KIT
- Four self-capacitance buttons with Philip Spring
- One six channel self-capacitance slider using Philip Springs
- One seven segment LED to display slider position
- Buzzer for audio feedback
- On-board Embedded Debugger module for programming/debugging and QDebug data streaming
- Connectivity with the Atmel QTouch Analyzer
Overview
The SAM C20 QTouch Robustness Evaluation kit demonstrates the high capacitive touch performance of the Peripheral Touch Controller (PTC) while achieving best-in-class conducted immunity and moisture tolerance required in home appliance and industrial applications.
The demo is based on the QTouch Library.
Key features:
- Ships with firmware that pass 15V conducted immunity test exceeding IEC/EN 61000-4-6 level 3 (10V)
- Advanced noise and moisture countermeasures adjustable for any environmental conditions
- Fast response time
The demo is supported by QTouch Composer 5.7, available for download free of charge at the Atmel Studio 7.0 Gallery.
Package Contents
- SAM C20 QTouch Robustness Demo kit
- USB TypeA/MicroB cable 1.5m
Application Notes
|
Title
|
Date
|
Document Category
|
|
|---|---|---|---|
| AT09363: PTC Robustness Design Guide | 10 Dec 2016 | Link | Application Notes |
