Part Number: EV25U57A
MIC69303RT_C-EB
The MCP14B101_PT-EB Evaluation Board
• MCP14B101_PT-EB features:
• 16 pin TSSOP ePAD MCP14B101 IC
• Adjustable output voltage down to 0.5V
• Logic controlled startup and shutdown.
• Input Voltage UVLO
• Output voltage Soft Start up.
• Thermal shutdown and current-limit protection
• Failure flag output.
• Adjustable output voltage determined by external resistor divider selected by jumper.
• Input load resistance for Bode plot generator equipment.
• Enable ON-OFF selectable by jumper.
• Enable jumper provision for current measurement.
• Fail Flag jumper provision for current measurement.
• Output Short to ground jumper provision for Maximum current protection measurement and Failure flag test.
• Input voltage and output voltage sense for accurate measurement
• Four-layer pcb board with ground planes for device heat removal
• Features Thermal shut down with hysteresis.
The MCP14B101_PQ-EB Evaluation Board
• MCP14B101_PQ-EB features:
• 16 pin VQFN ePAD MCP14B101 IC
• All the same features as MCP14B101_PQ-EB
The basic parameters of the evaluation board are:
• Input voltage range: 1.65V to 5.5V
• Adjustable output Voltage from 0.5V to 4.5V at VIN=VOUT+1V
• Output current from 10mA to 3A
Overview
The MCP14B101 is a constant-frequency, synchronous buck converter featuring a unique adaptive on-time control architecture. The MCP14B101 operates over an input supply range of 4.5V to 6V.
The MCP14B101 is available in an 16-pin TSSOP and VQFM packages, with a -40°C to +125°C ambient operating temperature range.
