Microchip’s AEC-Q100 Grade 0 (150C) Qualified Amplifiers
Read this post to learn more about our portfolio of AEC-Q100 Grade 0 qualified operational amplifiers and current sense amplifiers.
High-Temperature AEC-Q100 Grade 0 Op Amps for Extreme Conditions
In the demanding world of automotive and industrial applications, reliability and performance under extreme conditions are paramount. Microchip Technology Inc. has a portfolio of AEC-Q100 Grade 0 qualified operational amplifiers (op amps) and current sense amplifiers (CSA), designed to operate in temperatures ranging from -40°C to 150°C. This high-temperature rating ensures that our amps can withstand the harshest environments, providing unparalleled performance and reliability where it matters most.
Key Features
- Wide Temperature Range: Our AEC-Q100 Grade 0 amplifiers are qualified to operate from -40°C to 150°C, making them ideal for applications that require high-temperature resilience.
- Versatile Package Options: Available in various packages, including MSOP, SOT-23, SOIC and VDFN, these amplifiers offer flexibility in design and integration.
- Broad Offering: A range of bandwidth options and various current sense gain options, our amplifiers cater to a wide array of applications.
- Automotive and Industrial Applications: These amplifiers are perfect for automotive and industrial applications where high-temperature operation is critical.
Applications
- Automotive Electronics: From engine control units (ECUs) to transmission control modules, our high-temperature amplifiers ensure reliable performance in the extreme conditions found under the hood.
- Industrial Automation: In factory automation and process control, where equipment may be exposed to high temperatures, our amplifiers provide the stability and accuracy needed for precise control.
- Power Management: In power management systems, especially those exposed to high temperatures, our amplifiers ensure efficient and reliable operation.
Product Highlights
Standard Part Number |
Automotive Part Number |
Type |
Gain Bandwidth (MHz) |
Channel |
Min/Max Spec on Key Parameters |
T&R or Tube |
Package |
Gain |
MCP6401T-H/OTVAO |
Op Amp |
1 |
1 |
|
T&R |
5L/SOT-23 |
|
|
MCP6402-H/SNVAO |
Op Amp |
1 |
2 |
|
Tube |
8L/SOIC |
|
|
MCP6402T-H/SNVAO |
Op Amp |
1 |
2 |
|
T&R |
8L/SOIC |
|
|
MCP6404-H/SLVAO |
Op Amp |
1 |
4 |
|
Tube |
14L/SOIC |
|
|
MCP6404T-H/SLVAO |
Op Amp |
1 |
4 |
|
T&R |
14L/SOIC |
|
|
MCP6406T-H/OTVAO |
Op Amp |
1 |
1 |
Yes |
T&R |
5L/SOT-23 |
|
|
MCP6407-H/SNVAO |
Op Amp |
1 |
2 |
Yes |
Tube |
8L/SOIC |
|
|
MCP6407T-H/SNVAO |
Op Amp |
1 |
2 |
Yes |
T&R |
8L/SOIC |
|
|
MCP6409-H/SLVAO |
Op Amp |
1 |
4 |
Yes |
Tube |
14L/SOIC |
|
|
MCP6409T-H/SLVAO |
Op Amp |
1 |
4 |
Yes |
T&R |
14L/SOIC |
|
|
MCP6292-H/MSVAO |
Op Amp |
10 |
2 |
Yes |
Tube |
8L/MSOP |
|
|
MCP6292T-H/MSVAO |
Op Amp |
10 |
2 |
Yes |
T&R |
8L/MSOP |
|
|
MCP6C02T-020H/Q8BVAO |
CSA |
0.5 |
1 |
|
T&R |
8L/VDFN |
20 |
|
MCP6C02T-050H/Q8BVAO |
CSA |
0.5 |
1 |
|
T&R |
8L/VDFN |
50 |
|
MCP6C02T-100H/Q8BVAO |
CSA |
0.39 |
1 |
|
T&R |
8L/VDFN |
100 |
Conclusion
Our AEC-Q100 Grade 0 qualified amplifiers are engineered to meet the rigorous demands of high-temperature applications. With a wide range of package options and performance characteristics, these amplifiers provide the reliability and versatility needed for automotive, industrial and high temperature applications. Trust Microchip to deliver the high-temperature solutions that keep your systems running smoothly, even in the most challenging environments.
Explore our full range of AEC-Q100 Grade 0 qualified operational and current sense amplifiers and find the perfect solution for your high-temperature application needs.
