Our models and simulation tools are built to save time and cost for development with SiC-based power systems. Our models help you achieve real-world accuracy to get your design to market faster. Our MPLAB® SiC Power Simulator helps you evaluate mSiC™ products risk-free in multiple topologies using converter-level simulation models.
SPICE/PLECS Component Models
We created these SPICE models to simulate the characteristics of a typical device. However, as with any simulation model, it is not feasible to model exact device performance under all operating conditions. Please refer to the device data sheet for ratings and detailed device characterization. In addition to simulation, operation of these devices should be verified by in-circuit testing.
MPLAB® SiC Power Simulator
The MPLAB SiC Power Simulator calculates power losses and estimates junction temperature for SiC devices using lab testing data for common power converter topologies in DC-AC, AC-DC and DC-DC applications.
