Advanced Converter-Level Simulation for SiC Devices
Adopt SiC with ease, speed and confidence. The MPLAB® SiC Power Simulator calculates the power losses and estimates junction temperature for SiC devices using lab testing data for common power converter topologies in DC-AC, AC-DC and DC-DC applications. This simulator allows you to evaluate device performance quickly in your power converter design. Use this tool to:
- Select proper device and device configurations
- Evaluate the impact of different gate resistances
- Compare power loss and thermal performance for different devices and different working conditions
- Capture waveforms for passive component design needs
