Our dsPIC33 DSCs have built-in functionality and peripherals to make it easy to implement custom application-specific logic, couple system events more tightly and simplify system design. These peripherals minimize layout complexity and CPU intervention.
System Peripherals Simplify Layout Complexity and Reduce CPU Usage
Configurable Logic Cells (CLCs)
- Allow you to specify combinations of signals as inputs to a logic function and use the logic output to control other peripherals or I/O
- Provide greater flexibility and potential in embedded designs
Peripheral Pin Select (PPS)
- Enables flexible digital I/O pin mapping to a wide variety of external pins
- Allows you to choose from several output and input pins to connect to digital peripherals and simplify your board design
Peripheral Trigger Generator (PTG)
- A user-programmable sequencer that can generate complex trigger signal sequences to coordinate the operation of other peripherals
- Facilitates core-independent implementation of a variety of functions
Software Libraries
Quickly prototype your designs using MPLAB® Code Configurator.
Explore MPLAB Discover for complete source code and project examples to jumpstart your application.
dsPIC33 Digital Signal Controllers
- dsPIC33C DSCs—100 MHz
- dsPIC33E DSCs—70 MHz
Similar Devices
Loading
Similar Devices
dsPIC33C DSC Peripheral Deep Dive
This class presents deep-dive information on the architecture, set up and demonstration of dsPIC33C DSC peripherals.
