High-Performance Embedded, Measurement Control, Dual CAN, Functional Safety, Real-Time Control, Scalable
For demanding applications, the dsPIC33EP GP family of Digital Signal Controllers (DSCs) offers up to 70 MHz performance with very high peripheral integration and is optimized for real-time operations and measurement control. Offering the simplicity of a microcontroller, these DSCs feature a Digital Signal Processor (DSP) engine, a single-cycle 16 × 16 MAC unit and 40-bit accumulators to facilitate running high-speed precision control loops. This family is ideal for implementing math-intensive functions, such as DSP filtering of sensor inputs, and offers the right mix of features to address an array of automotive, industrial, medical and consumer applications.
dsPIC33EP GP DSCs are rated for operation up to 150°C ambient temperature for use in the most extreme automotive and industrial applications. For safety-critical applications, the DSCs include memory integrity check, fault monitoring and detection and a range of other features enabling functional safety compliance.
If your application requires wired or wireless connectivity, dsPIC33EP GP DSCs support a wide variety of communication protocols. These devices include up to two CAN modules, LIN, and other serial communication peripherals for wired applications. It is also easy to couple these DSCs with our Bluetooth®, Wi-Fi® and LoRa® modules for wireless connectivity and with our Ethernet and EtherCAT® controllers for wired connectivity.
Automotive
- Under-the-hood
- Camera control
- Home link systems
Automotive
- Under-the-hood
- Camera control
- Home link systems
Industrial
- Metering
- Factory Automation
- Smart relays
- Arc fault interrupters
Consumer
- Fingerprint scanners
- Smart IoT devices
- Portable devices
Medical
- Health monitors
- Fitness monitors
Simplify Your Microcontroller Design with MCC
Innovative Peripherals
Similar Devices
- Development Tools
- Software Development Tools
- Documentation
- Software
Development Tools
Starter Kits and Microsticks
Starter kits and Microsticks contain a device with demonstration hardware and software and an integrated debugger allowing a designer to quickly evaluate the family features. Microsticks also plug into standard breadboard for prototyping.
Digital Power Starter Kit: Allows the user to easily explore the capabilities and features of the dsPIC33F GS Digital Power Conversion family
dsPIC33E USB Starter Kit: Demonstrations support USB Host and Device applications with dsPIC33E device
dsPIC33EV 5V CAN-LIN Starter Kit: This USB-powered starter kit features the dsPIC33EV256GM106 with connections for CAN, LIN and SENT, as well as integrated programmer and debugger
Motor Control Starter Kit: Demonstrations support mTouch® Capacitive Touch technology and BLDC motor control
Development and Evaluation Boards
The Explorer 16/32 platform is the primary development board for 16-bit products. Explorer 16/32 is supplemented by numerous application-specific development boards including PICtail™ Plus boards and Click boards™ from MikroElektronika.
Explorer 16/32 Development Board: A modular and flexible development board for dsPIC® DSCs, with integrated programmer/debugger
Processor Plug-In Modules: Processor-specific Plug-in Modules
PICtail Plus Expansion Boards: Expansion board allowing evaluation of complex hardware and software solutions
Motor Control and Digital Power
Development boards for motor control and digital power applications range from simple starter kits to complete development platforms.
Digital Power Starter Kit: Allows the user to easily explore the capabilities and features of the dsPIC33F GS Digital Power Conversion family
Low-Voltage Motor Control Development Bundle: For evaluation of motor control application with 5V or dual motors
MCHV-2 Development Board: Provides a cost-effective method of evaluating and developing high-voltage sensored or sensorless Brushless DC (BLDC), Permanent Magnet Synchronous Motor (PMSM) and AC Induction Motor (ACIM) applications
MCLV-2 Development Board: Provides a cost-effective method of evaluating and developing low-voltage sensored or sensorless Brushless DC (BLDC) and Permanent Magnet Sychronous Motor (PMSM) applications
Motor Control Starter Kit: Demonstrations support mTouch Capacitive Touch technology and BLDC motor control
Emulators and Debuggers
The debuggers and programmers work across all PIC MCU platforms, are USB powered and are fully integrated with MPLAB® X IDE with features ranging from basic debugging to advanced emulation capability.
MPLAB REAL ICE™ In-Circuit Emulator: Next generation high-speed programmer and debugger with optional LVDS interconnect
MPLAB ICD 3: Cost-effective high-speed programmer and debugger
PICkit™ 3 In-Circuit Debugger/Programmer: Low-cost programmer and debugger
Software Development Tools
MPLAB® X IDE
This single Integrated Development Environment (IDE) supports all PIC MCUs and dsPIC DSCs. It provides a single integrated "environment" to develop code for embedded microcontrollers. It includes a library of Microchip-validated code examples to get started right away and integrates the MPLAB XC16 compiler while featuring "One Click" Make, Program, Debug/Execute operation.
MPLAB® Code Configurator
This free graphical programming environment generates seamless, easy-to-understand C code. Using an intuitive interface, it enables and configures a rich set of peripherals and functions. It minimizes reliance upon the product data sheet and reduces overall design effort and time while accelerating generation of production-ready code.
MPLAB® XC Compilers
MPLAB XC16 compilers provide a comprehensive solution for a project’s development software needs and comes in different optimization levels. It integrates with MPLAB X IDE to provide a full graphical front end. It can edit errors and create breakpoints to match the corresponding lines in source code. Single step through C and C++ source code to inspect variables and structures at critical points.
