32-bit Microcontroller (MCU) Early Access Program

Access Products Not Yet Released to the Public

Our early access program makes some of our latest innovative 32-bit MCUs available to you before they are officially released so that you can begin evaluating and developing as quickly as possible. Get started today by purchasing one of the early access Curiosity development kits shown below.

Our early access program now includes the PIC32CZ CA70 family.

PIC32CZ CA70

The PIC32CZ CA70 series of MCUs offers a path of increased memory and robust EMI noise rejection that is pin compatible to the popular SAM E7x/S7x/V7x families of devices.

We have one early access development kit available for the PIC32CZ CA70:

  • PIC32CZ CA70 Curiosity Ultra Development Kit (Part Number EA60E74A)

Key Features

  • 2 MB Flash, 512 KB SRAM
  • 64- to 144-pin package options
    • Pin compatible with SAM E/S/V7x families
    • EPad package versions available for additional EMI and temperature robustness
  • Arm® Cortex®-M7 core running at 300 MHz
  • Double-precision FPU for high-precision computing and accelerated data processing
  • High-performance internal memory architecture with user-configurable TCMs, system memory and 16 KB I-cache and D-cache
  • Dual Bosch CAN FD 1.0 controllers
  • 10/100 Ethernet MAC with IEEE® 1588
  • High Speed USB host and device with on-chip high-speed PHY
  • CMOS image sensor interface
  • Integrated security features including AES hardware encryption engines, TRNG and SHA-based memory integrity checker
  • Advanced analog front-end based on dual 2 Msps 12-bit ADCs including 16-bit average, up to 24 channels, offset error correction and gain control
  • Dual 2 Msps, 12-bit DACs and analog comparator
  • Extended industrial temperature range: −40°C to 105°C

Development Tools

PIC32CZ CA70 Curiosity Ultra Development Kit

Part Number: EA60E74A

Order now to get the PIC32CZ CA70 Curiosity Ultra Development Kit (EA60E74A) at an incredible 50% discount! Don't miss out on this exclusive deal to start your development with the amazing PIC32CZ2051CA70 before it goes into production.

Our PIC32CZ CA70 Curiosity Ultra Development Kit is a hardware platform for evaluating PIC32CZ2051CA70 Arm® Cortex®-M7-based microcontrollers (MCUs). This kit is supported by MPLAB® X Integrated Development Environment (IDE) to provide easy access to the features of the PIC32CZ CA70 and to help you integrate the device in a custom design.

The Curiosity Ultra series of evaluation kits includes an on-board embedded debugger, so no external tools are necessary to program or debug the PIC32CZ2051CA70 MCU.

Learn More

Documentation

Title
PIC32CZ CA70/MC70 Family Data Sheet Download
Title
PIC32CZ CA70 Curiosity Ultra User Guide Download
