AT32UC3L016 | Microchip Technology

Overview

Alternate products
Compare Products (2)
  • Part Family:AVR L Series
  • CPU Type:32-bit AVR MCU
  • MaxSpeed (MHz):50
  • Program Memory Size (KB):16
  • SRAM (KB):8
  • Temp. Range Min.:-40
  • Temp. Range Max.:85
  • Operation Voltage Min.(V):1.62
  • Operation Voltage Max.(V):3.6
  • SPI:5
  • I2C:2
  • UART:4
  • QSPI:0
  • Crypto Engine:No
  • Internal Oscillator:120Mhz, 8Mhz, 115Khz
  • Pin Count:48
Read more
  • Arithmetic performance — Integrated FPU increases precision and dynamic range in digital signal processing.
  • High data throughput — Peripheral DMA, multi-layered databus and large on-chip SRAM remove bottlenecks in high-speed communication.
  • Low power consumption — picoPower® technology delivers the industry''s lowest power consumption in active and sleep modes.
  • Software Library — All UC3 devices are supported by AVR Software Framework, a complete library of device drivers and middleware.
